W701A
Main Features
- 7" capacitive touch screen with 1 power key
- Android 4.4.4
- Supports 1*CVBS input & 3*RS232 & 1*RS485 & 1*CANBUS connection
- Supports LTE/WCDMA/GPRS, GPS, WiFi, Bluetooth
- 10V~32V / No battery
- Operation temperature: be able to work under -30°C ~ 80°C
Android Quad-core Mobile Data Terminal W701A
| Processor & Operating System | |
|---|---|
| CPU | Rockchip PX3 cortex-A9 Quad-core, 1.6GHz |
| Operating System | Android 4.4.4 |
| Memory | |
| DDR | 2GB |
| EMMC | 8GB |
| Display | |
| 7 inch WVGA 800*480, Capacitive screen | |
| LED backlight | |
| 350 nits | |
| Keypad & Buttons | |
| 1 power button | |
| 1 LED | |
| Interface ports | |
| RS232 serial ports | 3 |
| RS485(Optional) | 1 |
| CVBS Input | 1(default) |
| CANBUS(Optional) | 1 |
| USB ports | 1 x 2.0 USB Device |
| Accessible Expansion Slots | |
| Internal/External SD socket | TF card / max 128G Byte |
| Internal SIM card | GSM communication |
| I/O port | |
| Digital input x 4 line | |
| Digital output x 2 line | |
| Audio | |
| Speaker | 2W 8ohm, Size:40mm |
| EAR & MIC | |
| GPS | |
|---|---|
| GPS/BD Module ATGM332D | |
| 56 channels | |
| Sensitivity -163 dBm | |
| LTE/WCDMA | |
| WCDMA module | MU709, 900 MHz/1800 MHz/1900 MHz/2100MHz(default) |
| MU609 850 MHz/900 MHz/1800 MHz/1900 MHz | |
| LTE module(optional) | |
| Wireless Communication | |
| Bluetooth(Optional) | V3.0 Class II; support hand-free call |
| WIFI | Realtek 8189ES |
| Antenna | |
| GPS Antenna | External |
| GSM Antenna | External |
| Physical Characteristics | |
| Size | 190*118*25mm |
| Weight | approximately 2.5 kg |
| Environment | |
| Main Power | 10V~32V |
| Battery | No battery |
| Operating Temperature | -30℃ to +80℃ |
| Humidity | 5% - 90% |
